Кран за секакви терени Liebherr LTM 11200-9.1

Main Data:

Model / Type of crane LTM 11200-9.1 / AT

Max. capacity (75%) / max. loadmoment (tm) 1200 t at 2.5 m / 3232 tm

Year / First taken into operation 2020 / -

Working hours chasis (h) / date - h / 19.01.2020

Working hours superstructure (h) / date 8 h / 19.01.2020

Mileage (km) / date 6000 km / 19.01.2020

Data Chassis:

Truck chassis type / Width A90C / 3 m

Carrier cabin wide

Aircondition existing / available

Engine (make/type) / hp / kW Liebherr D 9508 A7-05 / 686 / 505

Engine exhaust-stage V

Gearbox manufacturer / Type ZF / SG / TC-Tronic

Crane driveable from below

Eddy current brake Telma

Drive and steering 18 x 8 x 18 / 1. - 9.

Type of axle suspension Niveaumatic

Size of wheels 14.00 R 25

Sparewheel 1

Controlled from support left, right

Support basis L/B 13,00 x 13,00 m

TÜV / SP-acceptance validity neu /

Data Superstructure:

Telescopic boom / boom sections 18,3 - 100 m / 8

Telescopic boom extension 10 m (V2) / 6 m (V3)

Guyed telescopic boom TY

Fixed Fly jib / Adapter 6,5 m / 0-60° hydr.

Rooster sheave NM / NI 65 t

No. of winches 2

Winch 1 cable pull / cable Ø 167 kN / 28 mm

Winch 2 cable pull / cable Ø 167 kN / 28 mm

Engine (make/type) / hp / kW Liebherr D 936 A7-05 / 367 / 270

Engine exhaust-stage V

Hookblocks / Crane hook (t) 112 t (DH) / 50 t / 16 t

Counterweight (t) 202 t

Working area limitation existing / available

Emergency operation of crane hydraulic available / existing

Two working floodlights (Xenon) at pivot section electrically adjustable existing / available

Aircondition existing / available

Safe load indicator Liebherr LICCON / 75 %

UVV-acceptance validity n.b.

Other features:

2nd hoist limit switch; 4 track pads 3,5 m x 2,4 m; power pack for self assembly of telescopic boom; removable outriggers; self assembly of the telescopic boom through 4 supporting cylinders; supporting base detection

Subject to change.

Subject to prior sale.

Complete data sheet on request.
